Explanation
The initial radiograph and clinical presentation (shortened, adducted, internally rotated leg) confirm a posterior hip dislocation. Posterior dislocations are frequently associated with posterior wall acetabular fractures. To radiographically evaluate the acetabulum, Judet views (45-degree oblique views) are utilized. The provided explanation image is an Obturator Oblique view. This view is taken with the patient rolled 45 degrees away from the affected side, with the beam centered on the affected hip. This specific orientation profiles the anterior column and the posterior wall of the acetabulum, making it the ideal view to evaluate for a posterior wall fracture following a dislocation. Conversely, the Iliac Oblique view (patient rolled 45 degrees toward the affected side) profiles the posterior column and anterior wall. Inlet and outlet views are primarily used to assess the pelvic ring, not the specific acetabular columns.

References:
- Judet, R., Judet, J., & Letournel, E. (1964). Fractures of the acetabulum: classification and surgical approaches for open reduction. Journal of Bone and Joint Surgery, 46(8), 1615-1646.
